Click the image to expand

OE Supplier Wheel Cylinder; Rear; 23.8mm ID Bore | 0014200418

Mercedes 220S, 220, 220SE, 200, 200D, 190C, 190SL, 190DC, 190B, 180 & more
$65.99
Reg
$68.74
List
$117.00
In Stock Status
In Stock Information Icon
Leaves warehouse within 1-2 business days.
  • You may also want a Mityvac Brake Bleeder Tool!

    This compact yet powerful unit bleeds up to 2 quarts per minute, and its simple operation allows clean, quick bleeding of brake and clutch lines.

    MV6830 Mityvac Brake Bleeder Tool
    $214.99
    Reg
    $223.95
    List
    $246.47
Loading...

Make Sure It Fits

P/N: 0014200418 OE Supplier
Description:
Rear; 23.8mm ID Bore
Early version wheel cylinder with large bore. 2 per car.
Cross References:
  • 001420041864
  • 020090
  • AT001420041864
  • R2301B1
  • W01331617270

Wheel cylinders are hydraulic rams that push brake shoes against brake drums to slow a wheel to a stop on wheels with drum brakes. They are cylinders with pistons extruding from either side, sealed in with o-rings and a boot to keep out dirt and debris. They have a hydraulic line connection and a bleeder screw on the back to remove air from the brake hydraulic system.

Symptoms of Faulty or Worn Out Wheel Cylinders
Wheel cylinders fail when the piston seals leak, when the wheel cylinder pistons get seized, or when the bleeder rusts and breaks. Wheel cylinders with leaking piston seals and broken bleeder screws allow hydraulic brake fluid to bypass the pistons. This results in the pistons not being pushed out and hydraulic fluid to leave the system and be replaced with air which prevents the wheel from slowing and will make the brake pedal feel spongy. Wheel cylinders with seized pistons will allow the brake pedal to feel normal but will prevent the pistons from pressing out the brake shoes to contact the drums and slow the wheels.

Replacing Your Mercedes Wheel Cylinders
Replacing wheel cylinders requires the removal of the brake drum and brake shoes to access the brake backing plate where the wheel cylinder is mounted. From there, you’ll need to disconnect the hydraulic line and unbolt the wheel cylinder for replacement. Replacing the brake shoes and drum is highly recommended when replacing a wheel cylinder.

Once the new wheel cylinder has been bolted in place, the hydraulic line has been reconnected, and the brake shoes and brake drum have been installed, the wheel cylinder and other wheel cylinders and brake calipers on the vehicle must be bled to remove all air from the brake hydraulic system. The wheel cylinders can be bled by pumping the brake pedal and holding it pressed, and then loosening the bleeder screw on the wheel cylinder. Once the bleeder screw is loosened, air will be forced out of the wheel cylinder being replaced by brake fluid resulting in the brake pedal dropping to the floor. Before releasing the brake pedal, the bleeder screw must be tightened to prevent air from entering back into the wheel cylinder when the pedal is released. This process must be repeated until no air comes out of the wheel cylinder and then repeated for each wheel cylinder and caliper.

View more Mercedes Wheel Cylinders.

Left = Driver side and Right = Passenger side.
All parts are priced individually unless identified as a set or kit. "Per car" notes identify how many of a given part your car has and "Left/Right or Front/Rear" notes means the part fits the left or right side of the car. These parts are still sold individually and you'll need to select the appropriate quantity if you plan to replace more than one of this item.

Frequently Viewed Together

We found 9 additional part(s) that are frequently viewed together.

Why Buy OEM & Genuine Replacement Auto Parts from AutohausAZ?

Auto parts at wholesale prices is what you will find at AutohausAZ. Have you been searching the web for auto parts for your vehicle? You have come to the right place! Here at Autohaus, we strive to offer low prices on quality replacement parts and providing first rate customer service.

What This OE Supplier Wheel Cylinder Fits?

Application information below is for reference only and should not be used to determine the exact vehicle fitment. Please use the "Make Sure It Fits" vehicle selection box above to determine the exact fitment and review any application notes. If you need any help determining if this part works with your vehicle, please don't hesitate to contact us.

Mercedes
60-63 - 180
60-62 - 190B
63-65 - 190C
For models with chassis serial number through 064105.
60-62 - 190DB
63-65 - 190DC
For models with chassis serial number through 099641.
60-63 - 190SL
66-67 - 200
For models with chassis serial number through 064105.
66-68 - 200D
For models with chassis serial number through 099641.
60-65 - 220
For models with chassis serial number through 048976.
60-65 - 220S
For models with chassis serial number through 070637.
60-66 - 220SE
For models with chassis serial number through 026840.
